Quiet Nema 17 Stepper Motor Small 3D Printer 0.9 New 1.68A 0.4A 42Bygh

  • 1
  • 2
  • 3

Brand Name : JSS-MOTOR

Model Number : 42HS34

Certification : CE ROHS

Place of Origin : CHINA

MOQ : 1pcs

Price : Negotiation

Payment Terms : T/T, Western Union

Delivery Time : 1-20days

Packaging Details : carton

Phase : 2

length : 34mm

Current : 1.7A

Shaft : 5mm

torque : 0.28N

Weight : 0.22kg

Contact Now

Quiet Nema 17 Stepper Motor Small Nema17 3D Printer 0.9 New 1.68A 0.4A 42Bygh

● Maximum holding torque 0.28Nm.
● Rated current 1.7A.
● Body length 34mm
● Shaft diameter 5mm

Model No. Step Angle(°) Rated Voltage(V) Rated Current(A) Phase Resistance(Ω) Phase Inductance(mH) Holding Torque(Kg.cm) Motor Length(MM) Lead Wires No. Motor Weight(Kg)
42HS29-0804 1.8 2.3 0.8 2.9 3 1.8 29 4 0.16
42HS34-0404

1.8

12

 0.4 30 35 3.2 34 4 0.22
42HS40-0804 1.8 5.4 0.8 6.8 12 4.5 40 4 0.28
42HS48-1504 1.8 4.2 1.5 2.8 5.5 5.5 48 4 0.38
42HS60-1504 1.8 3.8 1.5 2.5 6 7 60 4 0.55

Not all models are listed above, please contact us for more information

Quiet Nema 17 Stepper Motor Small 3D Printer 0.9 New 1.68A 0.4A 42Bygh
