Nema23 57hs112 Stepper Motor 3N.M 3a 4 lead 2 phase 425Ozin CNC Kits

Product Categories

Changzhou Jinsanshi Mechatronics Co., Ltd

Contact Now

Brand Name : JSS

Model Number : 57HS112-3004A08-D21

Certification : CE SGS

Place of Origin : CHINA

MOQ : 1 pcs

Price : USD 15-18 pcs

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100000 pcs month

Delivery Time : 5-10 days

Packaging Details : Carton

Flange : 57*57mm

Holding torque : 3N.m or 425Ozin

Current : 3.0A

Inductance : 6.5mH

Length : 112mm+-1

Shaft diameter : 8mm or 6.35mm

Shaft length : customized

Colour : black

Rated voltage : 3.9V

Resistance : 1.3

Contact Now

Motor Specification

Model No	Step Angle(°)	Rated Voltage(V)	Rated Current (A)	Phase Resistance(Ω)	Phase Inductance (mH)	Holding Torque (Kg.cm)	Detent Torque(g.cm Max)	Rotor Inertia (g.cm²)	Motor Length (mm)	Leads No.	Motor Weight(Kg)
57HS41-2004	1.8	2	2	1	1.2	3.2	210	120	41	4	0.45
57HS41-1004	1.8	5.4	1	5.4	9.5	5.5	210	120	41	4	0.45
57HS41-2004	1.8	2	2	1	2.2	5	210	120	41	4	0.45
57HS51-1504	1.8	2.4	1.5	1.6	3.8	8.2	360	275	51	4	0.65
57HS51-2004	1.8	2.4	2	1.2	3	9	360	275	51	4	0.65
57HS51-2006	1.8	2	2	1	1.6	7	360	275	51	6	0.65
57HS56-1504	1.8	5.7	1.5	3.8	12	13.5	400	300	56	4	0.7
57HS56-3004	1.8	2.85	3	0.95	2.8	12	400	300	56	4	0.7
57HS56-2006	1.8	3.6	2	1.8	2.8	9	400	300	56	6	0.7
57HS64-3004	1.8	3.9	3	1.3	2.2	15	500	380	64	4	0.8
57HS76-2004	1.8	8.6	2	4.3	16.2	24	680	480	76	4	1
57HS76-3004	1.8	2.7	3	0.9	3.5	20	680	480	76	4	1
57HS76-4004	1.8	2.4	4	0.6	2.2	20	680	480	76	4	1
57HS82-3004	1.8	4.2	3	1.4	5	22	700	510	82	4	1.2
57HS82-4004	1.8	3	4	0.75	3.5	20	700	510	82	4	1.2
57HS100-3004	1.8	3	3	1	4.5	25	1000	680	100	4	1.4
57HS112-3004	1.8	3.9	3	1.3	6.5	30	1200	800	112	4	1.7
57HS112-3504	1.8	2.45	3.5	0.7	3	28	1200	800	112	4	1.7
Above only for representative products,products of special request can be made according to the customer request.

Torque Curve
